FE models are designed with increased safety “Ex e” for use in areas with potential hazard by dust (zone 21 and 22) or gas (Zone 1) in accordance with directive 94/9/EC and 2014/34/EU.
Vibrator motors with approval according to equipment group II 2.
EC type-examination: KEMA 03 ATEX 2233X, IECEx KEM10.0076X
Temperature class: T3 or T4
General specifications
Power Supply:
Voltages from 115 V to 690 V at 50 Hz available
Degree of protection:
IP 66
Thermal class:
F (155 °C) according to DIN EN 60034-1
Tropical insulation:
Standard
Thermal overload protection:
As standard PTC 120 °C
Electrical Connection:
Used exclusively on Ex e motors. These rubber hose assemblies are ideal for heavy mechanical stress according to VDE0282 Part 4, such as the type H07RN-F or A07RN-F or higher grade cable. There are 7-wire cable for zones 21 and 22 used as the PTC and can also be connected with this cable. Specifically: 3x phase, 1x Grounding, 2x PTC, 1x unoccupied. Some motors may also be a 4-wire cable for the live conductors and cables for the PTC, which a second cable gland is used. For this purpose, please contact FRIEDRICH Schwingtechnik.
Mounted on the motor terminal box is an ATEX-sealing plug and ATEX Cable gland. Use only certified components for assembly of the cable. The O-ring for sealing must be installed and undamaged.
Permissible Ambient Temperature:
-20 °C to +40 °C
Operating Mode:
Continuous operation (S1) and discontinuous operation at 100 % centrifugal force.
Hoods:
Hoods made from pressed sheet metal or stainless steel comprise the special shape. A silicone seal provides optimum protection against the ingress of dust and water.
Stock:
The built-in special cylindrical roller bearings with increased load capacity and clearance, are lubricated with a special grease for life.
Assembly:
Without limitation, motors can be mounted in any position.
Color Coating:
Standard RAL 6011. Other colors available on request.
Type Code:
The type code is read as follows:
First block number = Working Moment in kgcm
(working moment = 2 x static moment)
This is followed by a hyphen and then the pole number.
Where: 4 = 1460 rpm 6 = 980 rpm (at 50 Hz mains frequency).
Behind the second dash, the size is specified.
Vibrator motors with approval according to equipment group II 2.
EC type-examination: KEMA 03 ATEX 2233X, IECEx KEM10.0076X
Temperature class: T3 or T4
General specifications
Power Supply:
Voltages from 115 V to 690 V at 50 Hz available
Degree of protection:
IP 66
Thermal class:
F (155 °C) according to DIN EN 60034-1
Tropical insulation:
Standard
Thermal overload protection:
As standard PTC 120 °C
Electrical Connection:
Used exclusively on Ex e motors. These rubber hose assemblies are ideal for heavy mechanical stress according to VDE0282 Part 4, such as the type H07RN-F or A07RN-F or higher grade cable. There are 7-wire cable for zones 21 and 22 used as the PTC and can also be connected with this cable. Specifically: 3x phase, 1x Grounding, 2x PTC, 1x unoccupied. Some motors may also be a 4-wire cable for the live conductors and cables for the PTC, which a second cable gland is used. For this purpose, please contact FRIEDRICH Schwingtechnik.
Mounted on the motor terminal box is an ATEX-sealing plug and ATEX Cable gland. Use only certified components for assembly of the cable. The O-ring for sealing must be installed and undamaged.
Permissible Ambient Temperature:
-20 °C to +40 °C
Operating Mode:
Continuous operation (S1) and discontinuous operation at 100 % centrifugal force.
Hoods:
Hoods made from pressed sheet metal or stainless steel comprise the special shape. A silicone seal provides optimum protection against the ingress of dust and water.
Stock:
The built-in special cylindrical roller bearings with increased load capacity and clearance, are lubricated with a special grease for life.
Assembly:
Without limitation, motors can be mounted in any position.
Color Coating:
Standard RAL 6011. Other colors available on request.
Type Code:
The type code is read as follows:
First block number = Working Moment in kgcm
(working moment = 2 x static moment)
This is followed by a hyphen and then the pole number.
Where: 4 = 1460 rpm 6 = 980 rpm (at 50 Hz mains frequency).
Behind the second dash, the size is specified.
