Hubner encoder

OG 6  Download...
Square-wave cycles per turn: 100 - 512 OG 6 Servo flange
Max. output frequency: 120 kHz Solid shaft d= 6 mm
Logic level: HTL (C), TTL, TTL (R)
Permissible encoder temperature: -20 °C to +70 °C
Connection: Internal connection terminals
Weight: approx. 200 g
Shock resistance (6 ms): 1,000 m/s²
Protection class: IP 54 Ex II 3G 3D

   OG 60 • HOG 60  Download...
Square-wave cycles per turn: max. 10,000 OG 60 HOG 60 Servo flange (OG 60)
Max. output frequency: 250 kHz Solid shaft d= 6 mm (OG 60)
Logic level: HTL (C), TTL, TTL (R) Hollow shaft with clamping ring up to d= 12 mm (HOG 60)
Permissible encoder temperature: -30 °C to +85 °C
Connection: Plug connection High resolution
Weight: approx. 260 g (OG 60)
approx. 250 g (HOG 60)
Shock resistance (6 ms): 3,000 m/s²
Protection class: IP 65 Ex II 3G 3D

  OG 70 • HOG 70  Download...
Square-wave cycles per turn: 50 - 10,000 OG 70 / HOG 70 Servo flange (OG 70)
Max. output frequency: 250 kHz Solid shaft d= 6 mm (OG 70)
Logic level: HTL (C), TTL, TTL (R) Hollow shaft up to d= 14 mm (HOG 70)
Permissible encoder temperature: -20 °C to +85 °C
Connection: Internal connection terminals
Weight: approx. 360 g (OG 70)
approx. 240 g (HOG 70)
Shock resistance (6 ms): 1,000 m/s²
Protection class: IP 66   Ex II 3G 3D

   OG 71 • HOG 71  Download...
Square-wave cycles per turn: OG 71: 100 up to 1,024
HOG 71: 64 up to 2,048 OG 71 / HOG 71 Servo flange (OG 71)
Max. output frequency: 120 kHz Solid shaft d= 6 mm (OG 71)
Logic level: HTL (C), TTL, TTL (R) Hollow shaft up to d= 14 mm (HOG 71)
Permissible encoder temperature: -20 °C to +85 °C
Connection: Internal terminal strip
Weight: approx. 360 g (OG 71)
approx. 240 g (HOG 71)
Shock resistance (6 ms): 1,000 m/s²
Protection class: IP 66   Ex II 3G 3D

  AHE 7 • AFE 7  Download...
Square-wave cycles per turn: 60 - 5,000 AHE 7 AFE 7 Version US of OG 71/•HOG 71
Max. output frequency: 120 kHz 1/2" hollow shaft (AHE 7)
Logic level: HTL (C), TTL, TTL (R) 3/8" servo flange (AFE 7)
Permissible encoder temperature: -30 °C to +70 °C NPT 1/2" fitting
Connection: Internal connection terminals
Weight:    approx. 240 g (AHE 7)
approx. 380 g (AFE 7)

Shock resistance (6 ms): 1,000 m/s²
Protection class: IP 56

  HOG 75 • HOG 75 K  Download...
Square-wave cycles per turn: 250 - 2,500 HOG 75 Through-hole hollow shaft with clamping ring up to d= 26 mm (HOG 75)
Max. output frequency: 120 kHz
Logic level: HTL, TTL Cone shaft 1:10 (HOG 75 K)
Permissible encoder temperature: -30 °C to +85 °C
Connection: Internal connection terminals
Weight: approx. 320 g
Shock resistance (6 ms): 2,000 m/s²
Protection class: IP 56 Ex II 3G 3D

  OG 8 • HOG 8  Download...
Square-wave cycles per turn: 1 - 2,500 OG 8 HOG 8 EURO flange B10, solid shaft d= 11mm (OG 8)
Max. output frequency: 120 kHz Through-hole hollow shaft with clamping ring up to d= 16 mm (HOG 8)
Logic level: HTL (C), TTL, TTL (R)
Permissible encoder temperature: -30 °C to +85 °C
Connection: Internal connection terminals
Weight:    approx. 700 g (OG 8)
approx. 550 g (HOG 8)

Shock resistance (6 ms): 1,000 m/s²
Protection class: IP 54

  OG 9  Download...
Square-wave cycles per turn: 1 - 1,250 OG 9 EURO flange B10, solid shaft d= 11 mm
Max. output frequency: 120 kHz High HTL output current
Logic level: HTL, TTL, TTL (R) Bearing at each end
Permissible encoder temperature: -30 °C to +100 °C
Connection: Terminal box
Weight: approx. 900 g
Shock resistance (6 ms): 1,000 m/s²
Protection class: IP 55 Ex II 3G 3D

  OG 90  Download...
Square-wave cycles per turn: 1,000 - 10,000 OG 90 EURO flange B10, solid shaft d= 11 mm
Max. output frequency: 250 kHz High HTL output current
Logic level: HTL (C), TTL, TTL (R) High resolution
Permissible encoder temperature: -30 °C to +85 °C
Connection: Terminal box
Weight: approx. 1.5 kg
Shock resistance (6 ms): 1,000 m/s²
Protection class: IP 55

  HOG 9 • HOG 9 G  Download...
Square-wave cycles per turn: 1 - 2,500 HOG 9 Hollow shaft with clamping element up to d= 16 mm
Max. output frequency: 120 kHz
Logic level: HTL, TTL, TTL (R) Option: Cone shaft 1:10
Permissible encoder temperature: -30 °C to +100 °C High HTL output current
Connection: Plug connection Bearing at each end
Weight: approx. 700 g (HOG 9) Protection against shaft currents
    approx. 1,100g (HOG 9G) Twin encoder HOG 9 G
Shock resistance (6 ms): 1,000 m/s²
Protection class: IP 56 Ex II 3G 3D

  FOG 9  Download...
Square-wave cycles per turn: 1 - 2,500 FOG 9 EURO flange B10, solid shaft d= 11 mm
Max. output frequency: 120 kHz High HTL output current
Logic level: HTL, TTL, TTL (R) Bearing at each end
Permissible encoder temperature: -30 °C to +100 °C
Connection: Plug connection
Weight: approx. 860 g
Shock resistance (6 ms): 1,000 m/s²
Protection class: IP 56 Ex II 3G 3D

  POG 9   Download...
Square-wave cycles per turn: 1 - 2,500 POG 9 EURO flange B10, solid shaft d= 11 mm
Max. output frequency: 120 kHz High HTL output current
Logic level: HTL, TTL, TTL (R) Bearing at each end
Permissible encoder temperature: -30 °C to +100 °C Twin encoder POG 9 G
Connection: Terminal box
Weight: approx. 1.3 kg
Shock resistance (1 ms): 3,000 m/s²
Protection class: IP 56 Ex II 3G 3D

   POG 9 G  Download...
Square-wave cycles per turn: 1 - 2,500 POG 9 G EURO flange B10, solid shaft d= 11 mm
Max. output frequency: 120 kHz High HTL output current
Logic level: HTL, TTL, TTL (R) Bearing at each end
Permissible encoder temperature: -30 °C to +100 °C
Connection: Terminal box
Weight: approx. 1.7 kg
Shock resistance (1 ms): 3,000 m/s²
Protection class: IP 56 Ex II 3G 3D

  POG 90  Download...
Square-wave cycles per turn: 1,024 - 10,000 POG 90 EURO flange B10, solid shaft d= 11 mm
Max. output frequency: 250 kHz High HTL output current
Logic level: HTL, TTL, TTL (R) Bearing at each end
Permissible encoder temperature: -20 °C to +85 °C High resolution
Connection: large terminal box
Weight: approx. 1.5 kg
Shock resistance (11 ms): 1,000 m/s²
Protection class: IP 66 Ex II 3G 3D

   HOG 10  Download...
Square-wave cycles per turn: 1 - 2,500 HOG 10 Hollow shaft with clamping element up to d= 20 mm
Max. output frequency: 120 kHz
Logic level: HTL, TTL, TTL (R) Option: Cone shaft 1:10
Permissible encoder temperature: -40 °C to +100 °C
-50 °C to +100 °C (optional) High HTL output current
Connection: Internal connection terminals or large terminal box Protection against shaft currents
Weight: approx. 1.6 kg Twin encoder HOG 10 G
Shock resistance (6 ms): 2,000 m/s²
Protection class: IP 66 Ex II 3G 3D

  HOG 10 G  Download...
Square-wave cycles per turn: 1 - 2,500 HOG 10 G Hollow shaft with clamping element up to d= 20 mm
Max. output frequency: 120 kHz
Logic level: HTL, TTL, TTL (R) Option: Cone shaft 1:10
Permissible encoder temperature: -40 °C to +100 °C
-50 °C to +100 °C (optional) High HTL output current
Connection: Large terminal box Protection against shaft currents
Weight: approx. 2.2 kg
Shock resistance (6 ms): 2,000 m/s²
Protection class: IP 66 Ex II 3G 3D

   HOG 100  Download...
Square-wave cycles per turn: 1,024 - 10,000 HOG 100 Hollow shaft with clamping element up to d= 16 mm
Max. output frequency: 250 kHz
Logic level: HTL, TTL Option: Cone shaft 1:10
Permissible encoder temperature: -30 °C to +85 °C High HTL output current
Connection: Internal connection terminals or large terminal box High resolution
Weight: approx. 1.5 kg Protection against shaft currents
Shock resistance (6 ms): 1,000 m/s²
Protection class: IP 66 Ex II 3G 3D

  POG 10  Download...
Square-wave cycles per turn: 1 - 2,500 POG 10 / POG 10 G EURO flange B10, solid shaft d= 11 mm
Max. output frequency: 120 kHz High HTL output current
Logic level: HTL, TTL, TTL (R) Bearing at each end
Permissible encoder temperature: -40 °C to +100 °C
-50 °C to +100 °C (optional) Protection against inductive shaft currents with isolated coupling (e. g. K 35)
Connection: Large terminal box
Weight: approx. 1.6 kg Twin encoder POG 10 G
Shock resistance (6 ms): 2,000 m/s²
Protection class: IP 66
Ex II 3G 3D

  POG 10 G  Download...
Square-wave cycles per turn: 1 - 2,500 POG 10 / POG 10 G EURO flange B10, solid shaft d= 11 mm
Max. output frequency: 120 kHz High HTL output current
Logic level: HTL, TTL, TTL (R) Bearing at each end
Permissible encoder temperature: -40 °C to +100 °C
-50 °C to +100 °C (optional) Protection against inductive shaft currents with isolated coupling (e. g. K 35)
Connection: Large terminal box
Weight: approx. 2.4 kg
Shock resistance (6 ms): 2,000 m/s²
Protection class: IP 66
Ex II 3G 3D

  HOG 11 (Offshore)  Download...
Square-wave cycles per turn: 1 - 2,500 HOG 11 Hollow shaft with clamping element up to d= 16 mm
Max. output frequency: 120 kHz Option: Cone shaft 1:10
Logic level: HTL, TTL, TTL (R) Protection against inductive shaft currents
Permissible encoder temperature: -30 °C to +100 °C Special corrosion protection e.g. for offshore
Connection: Large terminal box Option: Hybrid bearing
Weight: approx. 1.6 kg Option: Earthing brush for capacitive shaft currents
Shock resistance (6 ms): 2,500 m/s² Option: Heating for use down to -55°C
Twin encoder HOG 11 G
Protection class: IP 67 Ex II 3G 3D

  HOG 11 G (Offshore)  Download...
Square-wave cycles per turn: 1 - 2,500 HOG 11 G Hollow shaft with clamping element up to d= 16 mm
Max. output frequency: 120 kHz Option: Cone shaft 1:10
Logic level: HTL, TTL, TTL (R) Protection against inductive shaft currents
Permissible encoder temperature: -30 °C to +100 °C Special corrosion protection e.g. for offshore
Connection: Large terminal box Option: Hybrid bearing
Weight: approx. 2.2 kg   Option: Earthing brush for capacitive shaft currents
Option: Heating for use down to -55°C
Shock resistance (6 ms): 2,500 m/s²
Protection class: IP 67 Ex II 3G 3D

  POG 11 (Offshore)  Download...
Square-wave cycles per turn: 1 - 2,500 POG 11 EURO flange B10, solid shaft d= 11 mm
Max. output frequency: 120 kHz Protection against inductive shaft currents with isolated coupling (e. g. K 35)
Logic level: HTL, TTL, TTL (R)
Permissible encoder temperature: -30 °C to +100 °C Special corrosion protection e.g. for offshore
Connection: Large terminal box Option: Hybrid bearing
Weight: approx. 1.8 kg Option: Heating for use down to -55°C
Shock resistance (6 ms): 3,000 m/s² Twin encoder POG 11 G
Protection class: IP 67 Ex II 3G 3D

  POG 11 G (Offshore)  Download...
Square-wave cycles per turn: 1 - 2,500 POG 11 G EURO flange B10, solid shaft d= 11 mm
Max. output frequency: 120 kHz Protection against inductive shaft currents with isolated coupling (e. g. K 35)
Logic level: HTL, TTL, TTL (R)
Permissible encoder temperature: -30 °C to +100 °C Special corrosion protection e.g. for offshore
Connection: Large terminal box Option: Hybrid bearing
Weight: approx. 2.4 kg Option: Heating for use down to -55°C
Shock resistance (6 ms): 3,000 m/s²
Protection class: IP 67 Ex II 3G 3D

  HOG 12  Download...
Square-wave cycles per turn: 600, 1,024 HOG 12 Through-hole hollow shaft with clamping ring up to d= 45 mm
Max. output frequency: 120 kHz
Logic level: HTL (C), TTL, TTL (R)
Permissible encoder temperature: -30 °C to +85 °C
Connection: Cable connection
Weight: approx. 1 kg
Shock resistance (6 ms): 1,000 m/s²
Protection class: IP 54

   HOG 131 (Offshore)  Download...
Square-wave cycles per turn: 1,024 - 3,072 HOG 131 Through-hole hollow shaft with clamping ring up to d= 36 mm
Max. output frequency: 120 kHz
Logic level: HTL, TTL, TTL (R)
Permissible encoder temperature: -40 °C to +100 °C
Connection: Large terminal box
Weight: approx. 4 kg
Shock resistance (6 ms): 2,000 m/s²
Protection class: IP 56 Ex II 3G 3D

  EGZ 14 • AG 14  Download...
Square-wave cycles per turn: 250 - 2,500 EGZ 14 / AG 14 Through-hole hollow shaft up to d= 70 mm
Max. output frequency: 120 kHz Especially for lift drives
Logic level: HTL (C), TTL, TTL (R)
Permissible encoder temperature: -30 °C to +70 °C
Connection: Plug connection (EGZ 14)
Terminal box or plug connection (AG 14)
Weight: approx. 1.2 kg
Shock resistance (6 ms): 1,000 m/s²
Protection class: IP 20, IP 54

   HOG 16  Download...
Square-wave cycles per turn: 250 - 2,500 HOG 16 Through-hole hollow shaft with clamping element up to d= 38 mm
Max. output frequency: 120 kHz
Logic level: HTL, TTL, TTL (R) High HTL output current
Permissible encoder temperature: -20 °C to +100 °C Slip-ring earthing contact
Connection: Terminal box Option: Redundant scanning
Weight: approx. 4 kg
Shock resistance (6 ms): 3,000 m/s²
Protection class: IP 66 Ex II 3G 3D

  HOG 161  Download...
Square-wave cycles per turn: 250 - 2,048 HOG 161 Through-hole hollow shaft with clamping ring up to d= 75 mm
Max. output frequency: 120 kHz
Logic level: HTL, TTL, TTL (R) Option: Redundant scanning
Permissible encoder temperature: -20 °C to +85 °C
Connection: Terminal box
Shock resistance (6 ms): 1,000 m/s²
Protection class: IP 54
    Ex II 3G 3D

  HOG 163 (Offshore)  Download...
Square-wave cycles per turn: 250 - 5,000 HOG 163 Through-hole hollow shaft with clamping ring up to d= 75 mm
Max. output frequency: 120 kHz
Logic level: HTL, TTL, TTL (R) Insulated bearings
Permissible encoder temperature: -30 °C to +85 °C Special corrosion protection
Connection: Large terminal box Option: Redundant scanning
Weight: approx. 3.5 kg
Shock resistance (6 ms): 1,000 m/s²
Protection class: IP 56 Ex II 3G 3D

  HOG 165 (Offshore)  Download...
Square-wave cycles per turn: 250 - 5,000 HOG 165 Hollow shaft with clamping element up to d= 38 mm
Max. output frequency: 120 kHz
Logic level: HTL, TTL, TTL (R) Special corrosion protection
Permissible encoder temperature: -30 °C to +100 °C Option: Protection against shaft currents
Connection: Large terminal box Option: Slip-ring earthing contact
Weight: approx. 4 kg Option: Redundant scanning
Shock resistance (6 ms): 3,000 m/s²
Protection class: IP 67 Ex II 3G 3D

   HOG 22 • HOG 220  Download...
Square-wave cycles per turn: HOG 22: (720 - 4,000)
HOG 220: (1,024) HOG 22 Through-hole hollow shaft with clamping ring up to d= 115 mm
Max. output frequency: 120 kHz
Logic level: HOG 22: HTL (C), TTL, TTL (R)
HOG 220: HTL, TTL, TTL (R)
Permissible encoder temperature: -30 °C to +85 °C
<
